Avatars

An avatar is a graphical representation of an entity in Unblu.

Avatars fulfil a variety of functions in Unblu UIs:

They indicate who is participating in a conversation.
They make it easy to discern who contributed what in a conversation
They provide access to additional information about conversation participants.
They are also used in the Agent Desk and the Configuration Interfaces to determine who a setting or property refers to. This is particularly useful if entities have personalized avatars.

The following entities may have an avatar:

accounts
bots
named areas
persons
teams
users

Default avatar

The default avatar is generated on the basis of the name of the entity it represents. It consists of two letters on a single-color background. If the entity’s name consists of a single word, the avatar will use the first two letter of the entity’s name. For entities with names consisting of two or more words, the avatar will use the first letters of the first and last word in the entity’s name.

The background color is drawn from the set of colors specified in the configuration property com.unblu.theme.color.secondaryColorMap.

Unblu assigns an entity’s default avatar a background color based on the entity’s name. This way, the default avatars of all or most participants in a conversation should have different background colors (provided the secondary color map contains sufficient colors). The following picture shows the avatars of two visitors, Sven Hoek and Stephen Hawking, from the same conversation. Note that their avatars have different background colors, even though their initials are the same:

Default avatars for two visitors with the same initials

Visitors only ever have a default avatar.

Personalized avatar

Accounts, bots, named areas, teams, and users can all have personalized avatars. The image used for a personalized avatar must be a PNG or JPEG file and must be no larger than 5 MB. We recommend you use an image 256x256 pixels large. If you use a larger image, it will be cropped to the appropriate size from the center of the uploaded image.

Avatars cannot be shared between different entities. This means that if you want to use the same image for multiple entities, you will have to create a personalized avatar for each entity using the same image.

If you do wish to use the same image for more than one entity, you should check whether you can take advantage of the avatar fallback behavior.

Personalize a user avatar

Users can upload an image to personalize their avatars.

Click on your avatar in the upper right-hand corner of the Agent Desk and select Manage profile.
On the General tab, click on Select image to choose and upload an image for your avatar.

Alternatively, supervisors and admins can change a user’s avatar image.

Click on Users in the sidebar of the Account Configuration interface and select the user in question. This gives you access to the user’s profile.
Select and upload an image the same way a user would.

Personalize a team avatar

Supervisors and admins can change the avatar image for a team.

Click on Teams in the Account Configuration interface.
Select the appropriate team to open the team’s general profile tab.
You can then select and upload an image with the Select image button.

Personalize a named area avatar

Admins can personalize the avatars of named areas.

Click on Named areas in the sidebar of the Account Configuration interface.
The rest of the procedure is the same as for a team.

Personalize an account avatar

Admins can also personalize the avatar of an entire account.

Click on Overview in the sidebar of the Account Configuration interface.
In the overview, click on the Edit account button. This will open a modal page where you can upload an image for the account avatar.

Personalize a bot avatar

Bot avatars can only be personalized with the Web API. See below for further details.

Fallback behavior

Your organization may prefer not to use the default avatars for anyone but visitors. In that case you can configure Unblu to fall back on the avatar of another entity if the current entity doesn’t have a personalized avatar.

The fallback behavior is configured separately for conversation recipients and conversation participants (i.e. users).

Bots do not have fallback avatars.

Recipient fallback behavior

When a visitor initiates a conversation, Unblu sends an invitation to potential participants. Which users receive an invitation is determined by the conversation’s recipient.

The recipient’s avatar is displayed in the conversation list on the individual UI overview. If the configuration property com.unblu.visitor.ui.alwaysDisplayRecipientInConversationOverview is false, it is replaced by the avatar of the agent who redeemed the invitation to join the conversation.

For recipients, the fallback order is:

person → team → parent team → account
named area → account

So, if the recipient of a conversation is a person who doesn’t have a personalized avatar, the personalized avatar of the team they are a member of will be used. If that team has neither a personalized avatar nor a parent team, the account’s personalized avatar is used. If the account doesn’t have a personalized avatar, the default avatar for the account will be used.

To activate fallback behavior for recipients, set the configuration property com.unblu.messenger.useRecipientAvatarFallback to true.

Person fallback behavior

In the course of a conversation, participants in a conversation are represented by their avatars. A participant is always a person.

For persons, the fallback order is:

person → team → parent team → account

If a person doesn’t have a personalized avatar, the personalized avatar of the team they are a member of will be used. If that team has neither a personalized avatar nor a parent team, the account’s personalized avatar is used. If the account doesn’t have a personalized avatar, the default avatar for the account will be used.

To activate fallback behavior for persons, set the configuration property com.unblu.messenger.usePersonAvatarFallback to true.

Person fallback behavior only applies to users. Visitors are always represented by default avatars.

Fallback behavior in the Agent Desk and the Account Configuration interface

In the Agent Desk and the Account Configuration interface, users, teams, and named areas are also represented by their avatars. However, avatars in these interfaces are always the avatar of the entity in question. If the entity does not have a personalized avatar, its default avatar will be used.

Other avatar features

In the Agent Desk and the Individual UI, the avatar is used for some additional features.

Availability badge

The avatar indicates users' availability with a badge in the lower right-hand corner.

A green badge indicates that the user is online.
A yellow badge indicates that the user is unavailable.
If no badge is present, the user is offline.

Visitors are only ever online or offline. Their avatars will never sport a yellow badge.

Clicking on an avatar that represents a user or a person provides access to the person info menu. In the following picture, the agent has clicked on the visitor’s avatar. They can see that the visitor is the primary visitor in the conversation and is not authenticated. Furthermore, they can launch various types of collaboration directly from the menu.

Avatars and the Web API

The Web API includes an endpoint to read avatars. Calls to the avatars/read endpoint return an Avatar Model which contains the avatar’s image. Please refer to the Avatar Web API documentation for further information.

The Web API also includes an endpoint to create avatars. However, we do not recommend creating an avatar this way since it is not possible to link the avatar with an entity afterwards.

If you want to retrieve the avatar of a particular entity, you can call the entity type’s read endpoint with the expand parameter and the avatar value.

The following call would read a team’s data and return its avatar.

Listing 1. An API call to read a team’s data and retrieve its avatar

GET http://<unblu-server>/unblu/rest/v3/teams/read/id=wLnF0JpARJ2bi_GwwIb0Fg

This is the response body the call would return:

Listing 2. Response body of the API call with the parameter expand=avatar

{
    "$_type": "Team",
    "id": "wLnF0JpARJ2bi_GwwIb0Fg",
    "creationTimestamp": 1591609100000,
    "modificationTimestamp": 1591609100000,
    "version": 1,
    "accountId": "T-fc_lVIR_WNvY1ZX9ZA0w",
    "avatar": {
        "$_type": "Avatar",
        "id": "cA7Lm5ixACAB72KPdSUwA",
        "creationTimestamp": 1597144915490,
        "modificationTimestamp": 1597144915490,
        "accountId": "T-fc_kUHQ_WNvY1ZX9ZA0w",
        "imageZoomFactor": null,
        "imageXPositionRatio": 0.5,
        "imageYPositionRatio": 0.5,
        "imageRotationAngle": 0,
    },
    "name": "Commercial Advisors",
    "parentId": "U6ApJUqpSKHiG9bReFfpjg",
    "description": "Team for Commercial Client Advisors",
    "configuration": null,
    "metadata": null
}

Without the expand=avatar parameter, the call would return the avatar’s ID instead of the Avatar model:

Listing 3. Result of the same API call without expand=avatar

{
    "$_type": "Team",
    "id": "wLnF0JpARJ2bi_GwwIb0Fg",
    "creationTimestamp": 1591609100000,
    "modificationTimestamp": 1591609100000,
    "version": 1,
    "accountId": "T-fc_lVIR_WNvY1ZX9ZA0w",
    "avatar": "cA7Lm5ixACAB72KPdSUwA",
    "name": "Commercial Advisors",
    "parentId": "U6ApJUqpSKHiG9bReFfpjg",
    "description": "Team for Commercial Client Advisors",
    "configuration": null,
    "metadata": null
}

Assigning an avatar to an entity

If you wish to assign a personalized avatar to an entity using the Web API, use the parameter expand=avatar in the call to create or update the entity. This gives you the possibility to upload an image for the avatar in the body of your call. The image is included using the data URI scheme.

The following example shows the body of a call to the namedareas/create endpoint to create a new named area. The image for the personalized avatar is based on a PNG file.

Listing 4. Creating a named area with a personalized avatar

{
  "$_type": "NamedArea",
  "id": null,
  "dateCreated": 0,
  "dateModified": 0,
  "version": 0,
  "accountId": "T-fc_kUHQ_WNvY1ZX9ZA0w",
  "name": "Mortgages",
  "description": "Named area for private mortgage",
  "type": "META_TAG",
  "avatar": {
    "$_type": "Avatar",
  }
}

Personalize a bot avatar with the Web API

Unlike with other entity types, bots' personalized avatars can only be added to the person with which the bot joins a conversation.

To add an avatar to a bot, call the persons/createOrUpdateBot endpoint with the expand=avatar parameter. Include an Avatar Model in the call body as you would when adding an image to the avatar of any other entity.

Listing 5. Adding a personalized avatar to a bot

{
    "$_type": "PersonData",
    "personSource": "VIRTUAL",
    "sourceId": "best.bot.id",
    "firstName": "Best",
    "lastName": "Bot",
    "username": "best.bot",
    "displayName": "Best Bot",
    "personType": "BOT",
    "avatar": {
        "$_type": "Avatar",
        andSoOnAndSoForth..."
    }
}
